Spiral Aerator

Float mounted aerator mixer on twin pontoons, 1.1 to 22 kW, for aeration tanks, oxidation ditches and sludge holding tanks at treatment works. Enquire from this page: it takes about a minute.

Enquire

Last updated

Floating aerator mixers on green pontoon floats aerating two treatment lanes, seen from above

What does Spiral Aerator include?

The Spiral Aerator draws air down through its spiral tube and drives it into the water with an anti rag impeller, so one unit both aerates and mixes. There is no blower house, no pipework in the tank and no gearbox to service.

It floats on two pontoons and is held by cables to the tank walls or bank, so it rides up and down with the water level. That makes it a good fit for upgrading an existing aeration tank or covering a lane while blowers are repaired.

What are the key specifications?

TypeFloat mounted, self aspirating aerator mixer
Power1.1 to 22 kW, 400 V, 50 Hz, 3 phase
Water depth1.5 to 3.0 m (small models), 2.5 to 4.0 m (large models)
DriveGearless, no oil
Materials in the waterStainless steel and GRP

Where does a Spiral Aerator work best?

  • Activated sludge lanes and oxidation ditches
  • Sludge holding tanks
  • Extra aeration during blower failure or upgrade works
  • Balancing tanks that need mixing as well as oxygen

Frequently asked questions

How do I ask about Spiral Aerator?

Use the Enquire button on this page, or add it to your enquiry list with other devices. You can also email [email protected].
